Double-Sided Toothed Synchronous Belt
Description
Material: TPU
Teeth Color: White
Model: Double-Sided Toothed Synchronous Belt
Specification
Product Name: Double-Sided Toothed Synchronous Belt
1. The pitch and tooth profile of double-sided toothed synchronous belts are identical to those of single-sided toothed synchronous belts.
2. Double-sided toothed synchronous belts can be categorized into two standard types based on the tooth arrangement:
DA-type double-sided toothed synchronous belts have symmetrical teeth on both sides, see Figure (A)
DB-type double-sided toothed synchronous belts have staggered teeth on both sides, see Figure (B)
Note: Our company can manufacture double-sided toothed synchronous belts with both symmetrical (DA) and staggered (DB) tooth configurations. Special specifications can be manufactured according to customer samples or drawings.
Double-Sided Toothed Synchronous Belt has the following properties:
Mechanical properties
- Dimensional stability
- pre-tension low-low noise
- Highly resistant to wear-no maintenance-good elasticity
- Linear speeds up to 80m/s
Chemical properties:
- Anti-aging, water solution,UV UVA,anti-ozone
- Operating temperature: -30℃~+80℃+100℃ short period of time can withstand the highest
- Highly resistant to oil, oil ester
- Anti most acids, alkali corrosion
Jarulan is available with all kinds of PU timing belts:
-Open end
-Truly endless
-Jointed
-Coated with rubber, cloth, PU, APL, foam, rough PVC, cleats, etc.
If our pu timing belt at10 high quality caters to your requirement, Welcome to buy high quality low price conveyor belt from our factory. As one of the leading China belt manufacturers and suppliers, we must be your best choice.
